I Mark Registration Controller

Name: I Mark Registration Controller
Brand: ACCELUS ROBOTICS PRIVATE LIMITED
Price: 27500.0 INR
Availability: InStock

Price 27500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

I Mark Registration Controller.

Benefits:

Independent operation of up to 3 heads implies 1/3 the cost of independent controllers.
I-Mark orientation can be programmed on the fly (useful for stopping at 180 degrees or zero degrees).
Motors programmed to stop at end of the cycle if no mark found implies motors do not keep running in case of inching mode or machine dry run.
Can achieve up to 120 ppm/ head using direct drive motor.
MODBUS available for remote parameter programming from PLC.
Motor Size and Torque optimized based on maximum acceleration and load constraints.

Salient Features:

Full control of speed and acceleration for individual motors useful for jerk-free operation
Can achieve more than 200 ppm/head with speed multiplier gearing
High-speed stepper operation up to 600 rpm.
LED indications for all inputs and outputs for easy debugging
Scrolling LED-based front panel with the keypad for operational status
Works with off-the-shelf stepper motors and drives (customer supplied)
Can drive servo motors (tested with Panasonic LiQi series and Fuji Faldic-W series motors and drives).
Can provide line driver outputs.2 level password protection for changing settings and changing factory programmed settings
DIN Mountable on a panel with easy access to all IO
